CES-34240-G
24 10/100/1000TX + 4 10G SFP+
Managed Switch
NT$99,999
SNMP網管
10G
1000M
1年保固
特 點
-
24 埠GIGA超高速乙太網路RJ-45埠口
-
4埠 GIGA 光纖SFP 埠口
-
輸入電壓範圍110V ~240 VAC
-
操作溫度 0°C to 50°C
-
符合安全規範
-
適用安防產業,一年保固
產品說明
CES-34240-G 是新一代 24 埠GIGABIT+4埠10G 乙太網路光纖交換器，擁有容納強大 L2 交換地址 16K、支援 128G 背板頻寬，並支援 8個優先權序列QOS， 802.1V protocol based VLAN，IGMP V2 V3，IP V6 等多項網管協議，為使用者帶來穩定且安全性高的可管理乙太網路傳輸服務。
擁有 24 埠 10M/100M/1G RJ45 埠口以及 4 埠10G SFP，高硬體效能與彈性化擴充，高埠數 GbE SFP 光纖接口特別適用於工業區、大樓自動化、社區寬頻建置、中小型企業光纖網路。
CES-34240-G 支援鋼製外殼及強固型設計, 0°C to 50°C的操作溫度，可搭配 CTI-10000-SM10 (支援10G SEP+) 系列光電轉換器使用，兼顧耐用與實用的網路設計。
技術規格
| IEEE Standards | EEE802.3 10Base-T Ethernet IEEE802.3u 100Base-TX IEEE802.3ab 1000Base-TX IEEE802.3z Gigabit Fiber IEEE802.3x Flow Control and Back Pressure |
|---|---|
| Switch Properties | Back-plane (Switching Fabric): 5.6Gbps Packet throughput ability (Full-Duplex): 1488100pps @64bytes |
| Transfer Rate | 14,881pps for Ethernet port 148,810pps for Fast Ethernet port 148,8100pps for Giga Ethernet port |
| Connectors | 1000 FX: 16 x 1000 SFP 10/100/1000M TX: 8 x RJ-45 with auto MDI/MDI-X function |
| MAC Address | 8K MAC addresses |
| Processing | Store-and-Forward |
| Network Cable | 10Base-T: 2-pair UTP/STP Cat. 3, 4, 5, 6 cable EIA/TIA-568 100-ohm (100m) 100Base-TX: 2-pair UTP/STP Cat. 5, 6 cable EIA/TIA-568 100-ohm (100m) 1000Base-TX: 2-pair UTP/STP Cat. 5, 6 cable EIA/TIA-568 100-ohm (100m) |
| Fiber Optical | Distance: Multi mode: 0 to 5 km, 1300 nm (50/125 μm, 800 MHz*km) 0 to 4 km, 1300 nm (62.5/125 μm, 500 MHz*km) Single mode: 0 to 40 km, 1310 nm (9/125 μm, 3.5 PS/(nm*km)) 0 to 80 km, 1550 nm (9/125 μm, 19 PS/(nm*km)) Min. TX Output: Multi mode: -20 dBm Single mode: 0 to 40 km, -5 dBm; 0 to 80 km, -5 dBm Max. TX Output: Multi mode: -14 dBm Single mode: 0 to 40 km, 0 dBm; 0 to 80 km, 0 dBm Sensitivity: -36 to -32 dBm(SM); -34 to -30(MM) |
| Protocol | CSMA/CD |
| Case Dimension | Metal case; 440mm(W)x205mm(D)x45mm(H) |
| Weight | 2200g |
| LED | Power Indicator : Green LED x 2 10/100/1000Base-T(X) RJ45 port indicator : Green LED x8 Amber x8 1000Base-SX/LX Fiber port indicator : Green LED x8 |
| Power Supply | 100~240 VAC Power input with internal redundant power |
| Consumption | Less than 30 Watts (Full load: Only Ethernet) |
| Overload Current | NC |
| Reserve Polarity | NC |
| Operating Humidity | 5% to 95% Non-condensing |
| Operating Temperature |
0°C~50°C |
| Storage Temperature |
-20°C~70°C |
| Certification | FCC CE |
| Warranty | 1 years |
